NDI Optical Trackers are the centerpiece of NDI's suite of advanced portable coordinate measurement solutions, dynamic motion measurement machines, and handheld laser scanners. With real-time, high-speed target tracking and support for multi-object, 6DOF measurement, the Optical Tracker brings unmatched ease of use to inspection and reverse engineering.

Dynamic Referencing

Anyone who measures on the shop floor will appreciate the added power of Dynamic Referencing, a unique feature that automatically compensates for movement between the part and Optical Tracker. Targets attached to the part continuously maintain a local frame of reference that ensures probe coordinates are always measured relative to the part. Now you can eliminate measurement drift and error by automatically maintaining part alignment throughout the entire inspection routine.

• Operate in unstable conditions
• Correct for vibration
• Overcome changes in setup caused by thermal effects
• Enable fixtureless measurement
• Reposition the part or Tracker at any time
• Reposition the part or Tracker at any time

top

Portable CMM

Key Features

• Instant tracking technology
• Large measurement volume
• Solid state operation with no moving parts
• Dynamic Referencing
• Key Benefits
• NDI's Portable CMM allows you to reduce production stops, rework, and scrap.
• Measure large objects at any location with a precision system that sets up in minutes
• Perform walkabout measurement without cables, linkages, or beam breaks using lightweight, operator-friendly touch probes.
• Reduce multiple setups with the system’s large measurement volume
• Measure in confined spaces with the system’s small, adjustable footprint
• Measure accurately in unstable environments with Dynamic Referencing (near stamping presses, forklifts, vibrating machinery, etc)

top

ScanTrack

Laser Scanning

Take non-contact, point-cloud measurement to a higher level with laser scanning systems powered by NDI’s advanced Optical Tracker. Quickly bring physical parts into the digital domain with handheld laser scanners that combine instant tracking performance with high-speed, non-contact surface scanning.

Key Features

• Instant tracking technology
• Compact and lightweight handheld scanner
• Large measurement volume
• Integrated touch probing
• Dynamic referencing
• Key Benefits
• Exceptional ease of use for higher measurement throughput
• Perform walkabout scanning without beam-breaks, mechanical linkages, or photogrammetry targets
• Use your preferred data collection program - all major point-cloud software applications are supported
• Conduct freeform scanning of difficult geometries from multiple angles of approach
• Reduce operator fatigue with ergonomic and lightweight scanner designs
• Use the system's large measurement volume to scan large parts in one setup
• Measure difficult surfaces without powder or spray, including shiny black
• Measure accurately in unstable environments with Dynamic Referencing (near stamping presses, forklifts, vibrating machinery,
